THIS PAGE IS TO MAKE ACCESSIBLE VARIOUS
PHOTOS TAKEN BY EISENBERG HAVEN ARCHITECTS AT HORMEL FIELD IN MEDFORD MASSACHUSETTS
THE PHOTOS ARE ONLY FOR REFERENCE PURPOSES ANYONE USING THESE
PHOTOS MUST VISIT THE SITE TO VERIFY THE EXISTING CONDITIONS.
HEATING AND HOT WATER
SYSTEMS REPLACEMENT
DESIGNER SERVICES
SCOPE
EVALUATION:
A. EVALUATION OF THE SYSTEMS IN PLACE.
B. ISSUE A LETTER
REPORT THAT MAKES RECOMMENDATIONS AS TO THE MOST COST EFFECTIVE REPLACEMENT HEATING AND HOT WATER SYSTEM, OR
SYSTEMS, FOR THE BUILDING. THE EVALUATION SHALL INCLUDE THE SHORT TERM
COSTS AS WELL AS ASSESSMENT OF EXPECTED SERVICE LIFE.
C. COST ESTIMATES FOR
THE VARIOUS OPTIONS.
POSSIBLE REPLACEMENT OPTIONS:
REPLACE THE EXISTING HEATING AND HOT WATER SYSTEM WITH NEW MODERN HIGH
EFFICIENCY EQUIPMENT
THAT SERVICES THE ENTIRE BUILDING AND INCORPORATES CONTROLS THAT ALLOW
INDIVIDUAL CONTROL OF THE SEPARATE AREAS THROUGH THE IMPLEMENTATION OF "ZONES".
REPLACE THE EXISTING HEATING AND HOT WATER SYSTEM WITH NEW
MODERN HIGH EFFICIENCY EQUIPMENT FOR EACH SECTION OF THE BUILDING.
CONTROLS SHALL BE LOCATED AT A CENTRAL LOCATION THAT WILL ALLOW FOR THE CONTROL
OF EACH SECTION OF THE BUILDING INDIVIDUALLY.
OTHER OPTIONS MAY INCLUDE VARIANTS OF THE ABOVE TWO POSSIBLE
SOLUTIONS AS WELL AS REUSING SOME OR ALL OF THE EXISTING SYSTEMS.
DESIGN:
PROVIDE PLANS AND SPECIFICATIONS AS REQUIRED SO THE OWNER CAN
PROCURE BIDS FOR THE REPLACEMENT OF THE HEATING AND HOT WATER SYSTEMS. IT
IS UNDERSTOOD THAT PLANS AND SPECIFICATIONS MUST CONFORM TO THE REQUIREMENTS OF
ALL APPLICABLE LOCAL, STATE AND FEDERAL PROCUREMENT LAWS.
CONSTRUCTION ADMINISTRATION:
REVIEW SUBMITTALS. MAKE TWO VISITS TO THE SITE, ONE DURING
THE CONSTRUCTION AND
ONE AT THE COMPLETION OF THE WORK. WHILE ON SITE THE WORK SHALL BE
REVIEWED FOR COMPLIANCE WITH THE PROJECT SPECIFICATIONS. IF DEVIATIONS ARE FOUND GENERATE A
LIST OF ITEMS THAT ARE NOT IN COMPLIANCE FOR THE OWNER.
TEMPORARY HEAT AND HOT WATER
GIVE THE OWNER ESTIMATED COSTS ASSOCIATED WITH THE
IMPLEMENTATION OF TEMPORARY HEAT AND HOT WATER. COORDINATE THE
IMPLEMENTATION OF TEMPORARY HEAT AND HOT WATER.
NOTE: THE EXISTING BOILER AND HOT WATER SYSTEM IS BEING
REMOVED UNDER A SEPARATE CONTRACT.
CLICK ON THE FOLLOWING PHOTOS FOR LARGER IMAGES: IF YOU
HAVE ANY QUESTIONS PLEASE CALL:
EISENBERG HAVEN ARCHITECTS INC
123 NORTH WASHINGTON STREET
BOSTON, MASSACHUSETTS 02114
617-227-1100 EX 24
OR
339-222-2003
ATTN :MR DEAN SMITH
|
OVERALL OF THE
BUILDING UNDER
THE STADIUM TAKEN
FROM THE PARKING LOT |
EXISTING MECHANICAL
SYSTEMS |
|
TYPICAL LOCKER ROOM |
EXISTING MECHANICAL
SYSTEMS |
|
DUCT WORK IN HALLWAY
LOCATION UNKNOWN |
EXISTING MECHANICAL
SYSTEMS |
|
PIPING IN BUILDING
LOCATION UNKNOWN |
EXISTING MECHANICAL
SYSTEMS |
|
STADIUM FROM FIELD SIDE.
BUILDING IS UNDER STANDS. |
EXISTING MECHANICAL
SYSTEMS |
|
STADIUM FROM FIELD
SIDE. BUILDING IS UNDER
STANDS. |
EXISTING MECHANICAL
SYSTEMS |
|
STADIUM FROM FIELD SIDE.
BUILDING IS UNDER STANDS. |
EXISTING MECHANICAL
SYSTEMS |
|
HEATER HUNG FROM THE
CEILING LOCATION
UNKNOWN IN THE BUILDING |
EXISTING MECHANICAL
SYSTEMS |
|
EXTERIOR OF BUILDING |
EXISTING GAS LINES |
|
EXTERIOR OF
BUILDING NEAR
CHIMNEY |
EXISTING GAS LINES |
|
NEAR CHIMNEY |
EXISTING GAS LINES |
|
NEAR CHIMNEY |
EXTERIOR OF BUILDING
PARKING LOT SIDE |
|
ACCESS TUNNEL
TROUGH BUILDING |
EXISTING MECHANICAL
SYSTEMS |
|
EXISTING MECHANICAL
SYSTEMS |
EXISTING MECHANICAL
SYSTEMS |
|
EXISTING MECHANICAL
SYSTEMS |
EXISTING MECHANICAL
SYSTEMS |
|
EXISTING MECHANICAL
SYSTEMS |
|
